Distributed

BoboCEP is able to be distributed over multiple devices for fault-tolerant CEP at the network edge. Each software instance is able to synchronise with one-another in a decentralised manner.

It accomplishes this by sharing any changes that occur to runs locally, and updating local runs when remote instances notify it of its updates. The type of message sent depends on the last successful communication that an instance has had with an external instance.

SYNC requests sync the most recent run changes: whether a run has completed, halted, or had its internal state updated with a new event.
PING requests simply ping the other instance if it has not sent a SYNC request in a while, to make sure the other instance is still online.
RESYNC requests are sent when an instance has not been able to SYNC or PING another for a while, and ensures that the remote instance has the full system state. These requests may fail several times before being successful, depending on whether the external instance ever comes back online or not, or whether it recovers from its network failure, for example.

Additionally, a RESET flag may be sent with messages to indicate to other instances that they should fully RESYNC with the instance that sent the flag. This is useful when a hardware or software crash requires an instance gets back up to speed; BoboCEP does not store internal state to disk.

Note

Distributed BoboCEP is designed to be deployed at the edge of a single network, ideally with only 2-3 software instances.

Distributed BoboCEP provides the additional benefit of being able to load-balance data input into the system, by simply delegating sensors to different BoboCEP instances and having them exchange their run changes accordingly.

Recovery Scenarios

BoboCEP is designed to handle errors and discrepancies with distributed processing in the least complex way possible, that does not rely on excessive message passing as part of its recovery strategy. Various scenarios, and their expected recovery strategies, are discussed below.

The scenarios below consider three distributed instances - A, B, and C - that are hosted on three separate devices.

Communication Failure

Cannot send data to another instance.

If some instance A is unable to communicate with B, then it will store all of the SYNC data that it has been unable to send to B in a data “stash” and will periodically reattempt sending the stash in the future.

If B enters the PING period, it will still attempt to send SYNC data if there is any in the stash or if a run is completed, halted, or updated in Decider in the meantime. If B enters the RESYNC period, its stash is wiped and it will be forced to fully resynchronise with all runs in the Decider in A.

Note

Decider is able to cache its n most recently completed and halted runs. These cached runs are sent during a RESYNC.

Run Complete

Multiple instances complete same run with different events.

In this scenario, the complex events produced by the different instances will have different histories: where the final event accepted by the respective runs will vary.

For simplicity, BoboCEP will not attempt to rectify the histories. This is because:

It is not possible to determine which history should be the one to keep; and
Inconsistent events will still be mostly comparable, in the sense that the accepted events must have satisfied the same predicate. For example: if the predicate requires a temperature between 0 and 5 Celsius, then all events must have data within that acceptable range anyway.

Run Halt

One instance completes run, another halts it.

For example:

A receives Run r from B which states that it is COMPLETE; however
A also receives Run r from C which states that it is HALTED.

In this scenario, COMPLETE takes precedent over HALT, and A will complete the run, producing a complex event accordingly. It will do this if the run is in progress, or if it has previously been halted by A.

It will not produce multiple complex events for the same run if it had already been completed by A previously.

Run Update

Update is multiple blocks ahead of local run.

For example, A receives an UPDATE for a run, where the update is several blocks ahead of where its local copy of the run is.

In this scenario, the local run is simply pushed forward to the new block, and the event history of the update replaces the local run history.

Update is behind local run.

In this scenario, the update is ignored.

One instance updates run, another halts it.

In this scenario, HALT takes precedent over UPDATE, and the local version of the run is HALTED.
